Product features:
Global intelligent control
High-precision acquisition and control
Stable and reliable software architecture and rich system functions
Application field:
Multichannel DAC Control Board
The multi-channel DAC control board is a high-performance control board suitable for a variety of development needs. The board is equipped with an ADC with a sampling rate of over 10 MSa/s at 16 bits, and 38 EPC DACs with a 2.7 MSa/s 12-bit accuracy for superior signal processing. Through the RS485 command system, users can easily control the start and stop of the algorithm, query the current status, and obtain abnormal alarm records. At the algorithm level, the FPGA is responsible for the underlying driving and computing of all ADCs and DACs, with a single-channel PER ≥ 17dB, a control accuracy of ≤ 0.1dB, a control repeatability of ≤ 0.2dB, and a recovery time of ≤ 200ms. In terms of overall structure, the MCB and the electrically polarized controller are cleverly integrated in the 3RU chassis to provide a comprehensive range of interfaces, including flanges, SMAs, power supplies, etc
Core technical indicators
Typical parameters
Single-channel PER
≥17dB
Single-channel PER control accuracy
≤0.1dB
Single-channel PER controls repeatability
≤0.2dB
Recovery time
≤200ms
