Product features:
High reliability
Pure Chinese localization
Application field:
1550 nm electro-optic intensity modulator
The LiNbO3 electro-optical intensity modulator based on M-Z push-pull structure has low half-wave voltage and stable physical and chemical characteristics, and the device has a high response rate, AIO-15 series is an analog electro-optical intensity modulator designed for the 1550nm band, with 2.5G10G20G40G rate optional, which is widely used in high-speed optical communication systems, optical Q-switched systems, laser mode-locking and optical fiber sensing and other fields.
Product model
AIO-15-2.5G AIO-15-10G AIO-15-20G AIO-15-40G
Operating wavelength
1550nm±25nm
3dB bandwidth (Typical)
2.5HGz 10HGz 18HGz 28HGz
Insertion loss
<4.5dB <4.5dB <4.5dB <4.5dB
ADC sampling rateSwitching extinction ratio @DC
>20dB >20dB >20dB >20dB
RF端 VΠ @ 1KHz
<3.5V <5V <5.5V <5.5V
Bias 端VΠ @1KHz
<5V <7V <7V <7V
