Product features:
High precision laser output
Stable high power
High frequency regulation
GPU CUDA acceleration
Compactness
Application field:
Ultrafast lasers
Optical fiber communication
Optical Material Processing and Surface Treatment
High precision measurement and detection technology
The iNFA seed source series includes two types of seed sources: 1030nm 5M/40M and 1550nm 80M/100M. The center wavelength is 1030 ± 5 nm as the reference, exceeding 16nm@3dB The wide spectral band provides more flexible optical options for experiments. With an average power of 20 mW and a pulse width that can be compressed to 200fs/100fs, it supports a repetition rate of 40 ± 0.5MHz, making it suitable for various application scenarios. 1550nm 80M/100M seed source, with a center wavelength of 1560 ± 5 nm as the reference, exceeding 46nm@3dB The wide spectral band provides a wider range of optical choices. The average power of 20 mW can be compressed to a pulse width of 100fs/50fs, with a repetition rate option of 80/100M ± 0.5MHz, providing more possibilities for experiments.
SPECIFICATIONS
1030nm 5M/40M种子源 1550nm 80M/100M种子源
Center wavelength
1030+/-5nm nm 1560±5nm
Bandwidth
>16nm@3dB >46nm@3dB
Average power
>20mW >20mW
Pulse width
<4-8ps（可压缩200fs/100fs） <4-8ps(可压缩到100fs/50fs)
Power stability
<0.5% RMS <0.5 RMS
Repetitive frequence
40±0.5MHz 80/100±0.5MHz
Polarization state
线偏振 线偏振
Power supply specifications
DC 12V DC 12V
Operation temperature
10-35℃ 10-35℃
Heat dissipation method
风冷 风冷
Warm-up time
<5 min <5 min
Size
标准尺寸<180*130*65nm(可定制成<100*95*39nm)
Weight
<2 Kg <2 Kg
